01 / GLASS
1 mLClear glass ampoules
1 cc · Clear glass
GLASS AMPOULES / PAINTINGWAH CANTT, PAKISTAN ↗
GLASS AMPOULES & PAINTING
Precision.
In glass.
Glass ampoules, thoughtfully manufactured, with an ampoule painting service for customer-specified finishes.
Five sizes. Clear and amber.
Batch checked.
Delivered across Pakistan.
Delivered across Pakistan.
AMX / GLASS SERIES
01Clear
02Amber
02 / SELECT YOUR FORMAT
Small details.
Every possibility.
1, 2, 3, 5 and 10 mL glass ampoules.
Each size in clear and amber.
1 mL = 1 cc
Choose your ampoule
02 / GLASS
1 mLAmber glass ampoules
1 cc · Amber glass
03 / GLASS
2 mLClear glass ampoules
2 cc · Clear glass
04 / GLASS
2 mLAmber glass ampoules
2 cc · Amber glass
05 / GLASS
3 mLClear glass ampoules
3 cc · Clear glass
06 / GLASS
3 mLAmber glass ampoules
3 cc · Amber glass
07 / GLASS
5 mLClear glass ampoules
5 cc · Clear glass
08 / GLASS
5 mLAmber glass ampoules
5 cc · Amber glass
09 / GLASS
10 mLClear glass ampoules
10 cc · Clear glass
10 / GLASS
10 mLAmber glass ampoules
10 cc · Amber glass
TECHNICAL REFERENCE
The details,
measured.
Form B / OPC glass ampoule dimensions, transcribed from the supplied specification sheets and translated into English.
ALL MEASUREMENTS IN MILLIMETRES1 mL
- Body diameter d1
- 10 ± 0.26
- Constriction diameter d2
- 6.3 ± 0.8
- Bulb diameter d3
- 7.8 ± 1.0
- Stem diameter d4
- 5.0 ± 0.6
- Dot diameter d7
- 2.0 ± 0.5
- Overall height h1
- 60.0 ± 1.0
- Bottom to constriction h4
- 25.0 ± 1.0
- Bottom to measuring point h5
- 57.0
- Ampoule body height h6
- min. 21.0
- Body wall thickness s1
- 0.5 ± 0.04
- Stem wall thickness s2
- min. 0.20
- Bottom wall thickness s3
- min. 0.20
- Circular run-out tolerance t
- ≤ 1.0
2 mL
- Body diameter d1
- 11.5 ± 0.26
- Constriction diameter d2
- 7.0 ± 0.8
- Bulb diameter d3
- 8.5 ± 1.0
- Stem diameter d4
- 5.5 ± 0.6
- Dot diameter d7
- 2.0 ± 0.5
- Overall height h1
- 70.0 ± 1.0
- Bottom to constriction h4
- 36.5 ± 1.0
- Bottom to measuring point h5
- 67.0
- Ampoule body height h6
- min. 32.0
- Body wall thickness s1
- 0.5 ± 0.04
- Stem wall thickness s2
- min. 0.20
- Bottom wall thickness s3
- min. 0.20
- Circular run-out tolerance t
- ≤ 1.0
3 mL
- Body diameter d1
- 13.30 ± 0.3
- Constriction diameter d2
- 8.0 ± 0.8
- Bulb diameter d3
- 9.2 ± 1.0
- Stem diameter d4
- 5.8 ± 0.6
- Dot diameter d7
- 2.0 ± 0.5
- Overall height h1
- 70.0 ± 1.0
- Bottom to constriction h4
- 36.5 ± 1.0
- Bottom to measuring point h5
- 67.0
- Ampoule body height h6
- min. 32.0
- Body wall thickness s1
- 0.5 ± 0.04
- Stem wall thickness s2
- min. 0.20
- Bottom wall thickness s3
- min. 0.20
- Circular run-out tolerance t
- ≤ 1.0
5 mL
- Body diameter d1
- 16.0 ± 0.30
- Constriction diameter d2
- 8.2 ± 1.0
- Bulb diameter d3
- 10.0 ± 1.0
- Stem diameter d4
- 6.0 ± 0.6
- Dot diameter d7
- 2.0 ± 0.5
- Overall height h1
- 87.0 ± 1.0
- Bottom to constriction h4
- 43.0 ± 1.0
- Bottom to measuring point h5
- 84.0
- Ampoule body height h6
- min. 38.5
- Body wall thickness s1
- 0.55 ± 0.05
- Stem wall thickness s2
- min. 0.20
- Bottom wall thickness s3
- min. 0.30
- Circular run-out tolerance t
- ≤ 1.7
10 mL — current dimensions available on request. “min.” indicates a minimum value. The supplied sheet lists h5 without a tolerance.
Request a specificationReference: supplied Form B / OPC dimension sheets. Final specifications are confirmed with your inquiry.
A CORE AMPOULEX SERVICE
Ampoule painting.
Finished to your brief.
Painting is one of our main services. Tell us which ampoule sizes and quantities you need, along with your desired colour or specification. Our team will confirm the finish, pricing and timing with you.
- 01Choose your format1, 2, 3, 5 or 10 mL
- 02Share your colourColour name or code
- 03Confirm the detailsAvailability and price
AMX / SURFACE SERVICEPAINT / 01
COLOUR / FINISHSPECIFIED WITH YOU
ILLUSTRATIVE FINISHCONFIRMED PER ENQUIRY
05 / THE WAY WE WORK
Considered.
From glass
to delivery.
Manufactured in Wah Cantt.
Supplied across Pakistan.
Your specification, understood.
Choose your capacity and glass colour. Share quantities, dimensions and any particular requirements.
Checked with care.
Batch checks are part of our process before glass ampoules leave the facility.
Painted to your specification.
For painting enquiries, share a target colour or code and we’ll confirm the finish with you.
Ready for the journey.
Careful packing and coordinated nationwide delivery, with the details agreed with you.
06 / LET’S MAKE IT HAPPEN
Your next
order starts
right here.
Choose your ampoules, request painting, or ask us about both. Our team will follow up with pricing, availability and delivery details.
